Level-X

Leveling System

The TOX innovation allows for quick compensation of floor irregularities through movable plate bases and easy installation of joists or frame components (e.g., made of wood, metal, plastic). What makes our novel leveling system Level-X so unique is the fact that only one person is needed to align joists or frame components, and there's no need for makeshift supports like shims. Each box contains 50 plate bases along with the appropriate setting tool.

Features

• Stepless height adjustment 0 - 40 mm
• Easy and quick installation saves time
• Levelling with just one person
• Movable plate base compensates for uneven floors
• Patent pending
• Universally applicable

Description & Application Area

• Installation of joists or frame components (e.g., made of wood, metal, plastic) that are aligned in height
• When installing joists for timber frame construction, it is essential to consider the requirements of the statics
• The Level-X leveling system is not a load-bearing component

Application:

< >

For structural components, the gap between the joist and the floor slab must be filled with mortar in a sufficiently secure and pressure-resistant manner. In addition, statics are required for safety-relevant components.
